INPUT SUPPLY : 230 V AC, 50Hz
SIZE : L 11.5” x W 8” x H 4.5”
WEIGHT : 2.3 Kg. Approx
TECHNICAL SPECIFICATIONS :
Input Current : 58 mA
Output Current : 60 mA
Galvanic Output : Low ripple D.C. continuous adjustable from 0 to 145 volts
Interrupted Galvanic
Frequency : 1, 2, 3, 5, 10, 30, 50, 60, 100 Hz
Pulse Width : 0.01, 0.03, .10, .30, .40, 1, 3, 10, 30, 100, 300 Milli Seconds
Faradic : 1 Milli Second pulsed width and 60 Hz Frequency. Amplitude continuously adjustable from 0 to 145 volts.
Surge Faradic
Contraction Period : Contraction period adjustable from 1 to 9 seconds
Rest Period : Rest period adjustable from 1 to 9 seconds
TENS : Pulse width 400 micro sec. & frequency 50 Hz
STANDARD ACCESSORIES :
- One pair plate electrode
- One pair Velcro Straps
- One point electrode
Note: As our products undergo continuous R&D for improvement, we reserve the right to change their specifications.
